TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin14
BI1 Configuration
3
MSV 46 1 = None
2=RemNSB
3 = Motion NO
4 = Motion NC
5 = Window
BI2 Configuration
3
MSV 47 1 = None
2 = Door Dry
3 = Override
4=Filter
5=Service
UI3 Configuration
3
MSV 48 1 = None
2 = COC/NH
3 = COC/NC
4=COS
5=SS
Menu Scroll
3
BV 49 0 = No Scroll
1 = Scroll Active
Auto Mode Enable
3
BV 50 0 = Disabled
1 = Enabled
Temperature Scale
3
BV 51 0 = °C
1=°F
Pipe Number (BO1 and BO2)
Configuration
3
MSV 52 1 = Two-Pipe
2 = Four-Pipe
AUX (BO5) Configuration
3
MSV 54 1 = Not Used
2 = NO with Occ
3 = NC with Occ
4=NOwithOccandFan
5 = NC with Occ and Fan
6 = Networked Controlled
Password Value AV 56 0 to 1,000
Fan Mode Sequence
3
MSV 57 1 = Low-Med-High
2 = Low-High
3 = Low-Med-High-Auto
4 = Low-High-Auto
5=On-Auto
Heating Setpoint Limit
3
AV 58 40.0°F/4.5°C to
90.0°F/32.0°C
Cooling Setpoint Limit
3
AV 59 54.0°F/12.0°C to
100.0°F/37.5°C
Setpoint Type
3
BV 60 0 = Permanent
1 = Temporary
Setpoint Function BV 61 0 = Dual Setpoints
1 = Attached Setpoints
Table 3: TEC26x6(H)-4 and TEC26x6H-4+PIR Series MS/TP Bus Objects
(Part 4 of 7)
Point Name Thermostat Point
(Type/Address)
Range
