Johnson Controls ZY Series User Manual

Table 88: ZY09 Charging Table System 2
Air Flow Indoor Db/Wb Outdoor DB Suction P Suction Temp. Liquid P Liquid Temp. Delta T Db Compr. amps
75 137 64 278 78 -26 7.2
85 137 62 323 88 -27 8.1300 Cfm/Ton 80/62
95 137 59 369 98 -27 8.9
75 137 62 275 78 -26 7.2
85 140 62 324 88 -25 8.1300 Cfm/Ton 80/67
95 143 62 374 99 -24 9.0
75 137 60 272 78 -27 7.1
85 143 62 325 89 -24 8.1300 Cfm/Ton 80/72
95 149 64 378 99 -21 9.1
75 132 60 276 78 -24 7.2
85 133 59 322 88 -23 8.1300 Cfm/Ton 75/62
95 135 58 369 98 -23 8.9
75 141 67 280 78 -23 7.3
85 143 65 326 89 -23 8.1400 Cfm/Ton 80/62
95 146 63 372 99 -23 9.0
75 142 66 279 78 -23 7.2
85 146 65 327 89 -22 8.1400 Cfm/Ton 80/67
95 149 64 376 99 -21 9.0
75 144 65 277 78 -23 7.2
85 148 65 328 89 -21 8.1400 Cfm/Ton 80/72
95 152 65 379 99 -20 9.1
75 136 63 278 78 -21 7.3
85 139 62 325 88 -20 8.1
400 Cfm/Ton 75/62
95 142 61 373 98 -20 9.0
Table 89: ZY12 Charging Table System 1
Air Flow Indoor Db/Wb Outdoor DB Suction P Suction Temp. Liquid P Liquid Temp. Delta T Db Compr. amps
75 135 59 284 81 -26 8.9
85 135 58 332 90 -26 10.0300 Cfm/Ton 80/62
95 135 58 380 98 -27 11.0
75 134 59 285 81 -26 9.1
85 138 59 334 91 -25 10.1300 Cfm/Ton 80/67
95 142 60 383 100 -24 11.0
75 132 58 285 81 -26 9.3
85 141 60 336 91 -23 10.1300 Cfm/Ton 80/72
95 149 62 387 101 -20 11.0
75 129 56 282 80 -23 8.9
85 131 56 330 89 -23 10.0300 Cfm/Ton 75/62
95 133 56 379 98 -23 11.0
75 139 61 285 83 -23 9.0
85 142 61 333 91 -23 10.0400 Cfm/Ton 80/62
95 144 61 382 100 -23 11.0
75 140 61 287 82 -22 9.1
85 144 62 336 91 -22 10.1400 Cfm/Ton 80/67
95 148 62 385 100 -21 11.1
75 140 61 289 82 -22 9.2
85 146 62 338 91 -20 10.2400 Cfm/Ton 80/72
95 151 63 388 100 -19 11.1
75 134 58 284 81 -20 9.0
85 137 58 332 90 -20 10.0
400 Cfm/Ton 75/62
95 140 59 381 99 -19 11.0
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A136
