English – 5
Specifications
Dimensions: FR 2113 MA FRM 13 A FR 2115 MA
Length 2,150 mm 2,150 mm 2,020 mm
Width 880 mm 880 mm 880 mm
Height (above steering wheel) 1,070 mm 1,070 mm 1,070 mm
Weight incl. cutting unit 250 kg 250 kg 260 kg
Track width, front 720 mm 720 mm 720 mm
Track width, rear 630 mm 630 mm 630 mm
Wheelbase 850 mm 850 mm 850 mm
Tyre dimensions 16 x 7.5 x 8 16 x 6.50 x 8 16 x 7.5 x 8
Air pressure 60 kPa 60 kPa 60 kPa
Max. permitted slope 15° 15° 15°
Engine: FR 2113 MA FRM 13 A FR 2115 MA
Manufacturer Briggs & Stratton Briggs & Stratton Briggs & Stratton
model 286707 model 286707 model 287707
Power 9.2/12.5 kW/hp 9.2/12.5 kW/hp 10.7/14.5 kW/hp
Displacement 465 cm
3
465 cm
3
465 cm
3
Fuel min. 85 octane min. 85 octane min. 85 octane
unleaded unleaded unleaded
Tank volume 7.2 litres 7 litres 7.2 litres
Oil SAE 30 or SAE 30 or SAE 30 or
10W/30, class SF-CC 10W/30, class SF-CC 10W/30, class SF-CC
Oil volume 1.4 litres 1.4 litres 1.4 litres
Starter Electric start Electric start Electric start
Transmission: FR 2113 MA FRM 13 A FR 2115 MA
Manufacturer Tuff Torq K 46 Tuff Torq K 46 Tuff Torq K 46
Oil SAE 10W/30 SAE 10W/30 SAE 10W/30
class SF-CC class SF-CC class SF-CC
Oil volume 2.2 litres 2.2 litres 2.2 litres
Gears, forward - - -
Gears, reverse - - -
Electrical system: FR 2113 MA FRM 13 A FR 2115 MA
Type 12 V, negative earthed 12 V, negative earthed 12 V, negative earthed
Battery 12 V, 24 Ah 12 V, 24 Ah 12 V, 24 Ah
Main fuse Flat pin 15 A Flat pin 15 A Flat pin 15 A
Spark plug Champion CJ8 or J8 Champion CJ8 or J8 Champion CJ8 or J8
Electrode gap 0.7 - 0.8 mm 0.7 - 0.8 mm 0.7 - 0.8 mm
Specifications
