Specifications
Inspection List
Parallelism, cutting unit with cutting height in position 1: ± 2 mm
Inspection of cutting height in position 1: Rear ejector = 37 ± 2 mm
Mulching = 45 ± 2 mm
Toothed belt tension, FRM 13 A, FR 2113 MA at 7 N of power, pushed in: 8 mm
Toothed belt tension, FR 2115 MA Automatic adjustment
Distance between support plate and drive belt: 3–6 mm
Distance between belt tensioning device’s lever arm and belt controller,
disengaged unit: 17 ± 5 mm
Tightening Torques Play
Drive disc steering 5-10 Nm Clutch cable, FR 13, FR 2111 8-10 mm
Line pulley steering cable 45 Nm Brake lever arm against impact, FR 13, FR 2111 0-1 mm
Belt pulley 35-40 Nm Brake lever arm, FR 13, FR 2111 7-9 mm
Blades 45-50 Nm Brake cable 1 mm
Blade bearings 20-25 Nm Cable, hydrostatic transmission pedals 0 mm
Belt tensioning wheel 15-25 Nm
Fitting screws, engine 20-25 Nm
Fitting screws, gearbox 20-25 Nm
Engine belt pulley 70-80 Nm
Wheel axle nuts 100-150 Nm
Cutting Unit: FR 2111 FR 13 FR 2113 A
Cutting width 850 mm 850 mm 850 mm
Cutting height 40-90 mm 40-90 mm 40-90 mm
Blade length 304 mm 304 mm 304 mm
Noise level 100 dB (A) 100 dB (A) 100 dB (A)
Weight 28 kg 28 kg 28 kg
Total width 950 mm 950 mm 950 mm
Cutting Unit: FR 2113 MA FRM 13 A FR 2115 MA
Cutting width 900 mm 900 mm 1,030 mm
Cutting height 45-95 mm 45-95 mm 45-95 mm
Blade length 440 mm 440 mm 410 mm
Noise level 100 dB (A) 100 dB (A) 100 dB (A)
Weight 40 kg 40 kg 47 kg
Total width 1,000 mm 1,000 mm 1,115 mm
