J+J J4C S20 Handbook

HANDBOOK_J4C SERIES 11
4
2
cams 2 / 4
3) To adjust the open posion to more than 90
0
.
Turn the wrench to an-clockwise direcon
- cams 2 and 4.
The cam 4 (confirmaon) should press the
lever of the micro switch a bit earlier than
the cam 2.
4
2
cams 2 / 4
4) To adjust the open posion to less than 90
0
.
Turn the wrench to clockwise direcon -
cams 2 and 4.
The cam 4 (confirmaon) must press the
lever of the micro switch a bit earlier than
the cam 2.
1) To adjust the close posion at less than 0
0
.
Turn the wrench to clockwise direcon -
cams 1 and 3.
The cam 3 (confirmaon) should press
the lever of the micro switch a bit earlier
than the cam 1.
3
1
cams 1 / 3
2) To adjust the close posion at more than 0
0
.
Turn the wrench to an-clockwise direcon
- cams 1 and 3.
The cam 3 (confirmaon) should press the
lever of the micro switch a bit earlier than
the cam 1.
3
1
cams 1 / 3
