EXTERNAL CONNECTING DIAGRAM
3 WIRES ON - OFF
J4C 20/85
J4C 140/300
A = Power supply plug
A: VAC 3 WIRES (Grey plug)
PIN 1 = Neutral + PIN 2 = Phase = Close
PIN 1 = Neutral + PIN 3 = Phase = Open
A: VDC 3 WIRES (Grey plug)
PIN 1 = (-) Negave + PIN 2 = (+) Posive = Close
PIN 1 = (-) Negave + PIN 3 = (+) Posive = Open
B = Volt free contact, plug
PIN 1 / PIN 2 = Close
PIN 1 / PIN 3 = Open
A B
A B
J4C 20/85
J4C 140/300
2 WIRES ON - OFF
A B
A B
A = Power supply plug
A: VDC 2 WIRES (Grey plug)
PIN 2 = (+) Posive + PIN 3 = (-) Negave = Close
PIN 2 = (-) Negave + PIN 3 = (+) Posive = Open
B = Volt free contact plug
PIN 1 / PIN 2 = Close
PIN 1 / PIN 3 = Open
J4C 20/85
J4C 140/300
POSITIONER
A B
A = Power supply plug
A: VAC 2 WIRES (Grey plug)
PIN 1 = Neutral + PIN 2 = Phase = Power supply plug
A: VDC 2 WIRES (Grey plug)
PIN1=(-) Negave + PIN 2=(+) Posive = Power supply plug
B = Volt free contact plug
PIN 1 / PIN 2 = Closed
PIN 1 / PIN 3 = Open
C = Instrumentaon Signal
C: Input signal : 4/20mA or 0/10V
PIN 1 = (-) Negave + PIN 2 = (+) Posive = Input signal
PIN 1 = (-) Negave + PIN 3 = (+) Posive = Output signal
A C
C
B
INSTRUMENTATION SIGNAL
NO VOLTAGE
