J+J J4C S20 - Assembly Instructions; Pieces; Preparing the Cover


HANDBOOK_58
PIECES
A - 1 Cover
B - 1 Plasc column
C - 1 DPS posioner PCB
D - 2 Sheet metal Fixing screws
E - 1 Plasc Fixing screws
PREPARING THE COVER:


A
C
D
E
B

cap
the o-ring


sleeve 1

Oring 




Fig.A




Fig.B
sleeve
O-ring
sleeve



cap
O-ring
cap
PLEASE READ CAREFULLY BEFORE MOUNTING.
VERY IMPORTANT!!!! PLEASE FOLLOW THE INSTRUCTIONS STEP BY STEP. BEFORE CON-
NECTING “A” PLUG TO THE ACTUATOR,
CHECK THAT THE VOLTAGE IS THE SAME AS THE ONE SPECIFIED ON THE LABEL (CARTER).
TO CONVERT A STANDARD (ON-OFF) J4C ELECTRIC ACTUATOR INTO A MODULATING
FUNCTION WITH POSITIONER, PROCEED AS FOLLOWS:

