INTERFACE PROGRAM - HOW IT WORKS?
INTERFACE PROGRAM FOR J4 Y J4C SERIES ACTUATORS ONLY.
Two RED buons appear on the screen.
Buon 1 shows the USB Interface connector is not
connected to the PC. It will change into GREEN color
when it is connected.
Buon 2 shows that the other side of the INTERFACE
cable should be connected as per (image 1) as
explained before. Connect it and apply voltage to
the actuator, following the connecon diagram label
on the cover of the actuator. Buon 2 should
change into GREEN color.
To select the language, click on (CHANGE LENGUAGE),
chose the language and click on CONTINUE.
If you click on PARAMETERS, the following screen
will open, showing the actuator parameters, loaded
during the mass producon process.
Short explanaon of each parameter:
Model: A 5 to 6-digit code. The last 3 digit show
us the actuator model.
PCB Version: Is the soware version of the PCB
CONTROL part.
The rest of the parameter values, belong to a
specific actuator model, in order to obtain the
best working features of each one.
In case we should change any of the parameters,
in order to be able to work in a different way, a
new file would be sent to you. It should be copied
on the PC, following the steps:
Press SELEC CONFIG - select the file on the screen.
Click on PROGRAM, the actuator would work
with a new configuraon.
To go back to the home menu, click on MAIN
MENU.
