J+J J4C S20 Handbook

HANDBOOK_J4C SERIES 10
INDEX
4
3
Cams 1 and 3 Cams 2 and 4
3
4
2
1
2
1
1) Cam 1 is to adjust the close posion.
2) Cam 2 is to adjust the open posion.
3) Cam 3 is to adjust the close posion confirmaon.
4) Cam 4 is to adjust the open posion confirmaon.
To ensure that the posion confirmaon works, adjust the
confirmaon cams (3 & 4) 3° (+/-1º) before the motor stop.
The standard actuators are always adjusted at 0º (close)
and 90º (open).
POSITION OF THE CAMS
CAM
