HANDBOOK_J4C SERIES 15
ACTUATOR OPERATIONAL STATUS
MODELS: 20, 35, 55, 85, 140 & 300
The LED Light provides visual communicaon between the actuator and the user.
The current operaonal status is shown by different LED colors.
Without power supply .........................................................................................................................................................................................................................................................
In open posion ...........................................................................................................................................................................................................................................................................
In close posion ...........................................................................................................................................................................................................................................................................
Opening ...................................................................................................................................................................................................................................................................................................
Closing ......................................................................................................................................................................................................................................................................................................
Torque limiter funcon on, moving from close to open.....................................................................................................................................................................
Torque limiter funcon on, moving from open to close.....................................................................................................................................................................
Actuator in MANUAL mode (Exceeded me) ..........................................................................................................................................................................................
The actuator has stopped (no close/no open posion) ..................................................................................................................................................................
In middle posion .....................................................................................................................................................................................................................................................................
ON-OFF ACTUATOR
ACTUATOR OPERATIONAL STATUS
INDEX
