LOCAL VISUAL POSITION INDICATOR
LOCAL VISUAL POSITION INDICATOR
All J4C actuators are supplied with a local visual posion indicator comprises a black base with a
yellow insert that shows, both the posion and direcon of rotaon (Fig.6).
The open and close posions have the following logos molded into the top cover OPEN 90 and CLOSE 0.
Opening = Closing =
Fig. 6 0 = CLOSE Fig. 6 90 = OPEN
TWO YELLOW INDICATORS:
For 3 way ball valve, L port.
THREE YELLOW INDICATORS:
For 3 way ball valve, T port.
