JRC JFE-582 User Manual

8 3. Installation
3.1 Installing the Recorder Unit
Flush-Mounted Equipment
4-φ7 or M6
Hole
Mounting hole dimensions
Max. height
Mounting bolt
170 or more
Cable entrance
Figure 3-1
Standard Tolerances
Classification
30 or less
30 to 120
121 to 400
401 to 1000
1001 to 2000
2001 to 3000
±1
±1.5
±2.5
±4
±6
±8


External Diameter
Coating Color: Panel: Munsel N4
Case: Munsel N7
Mass: 11k
g
Unit: mm

JRC JFE-582 Specifications

General

Brand	JRC
Model	JFE-582
Category	Marine Equipment
Language	English
