Chapter 3 INSTALLATION OF THE DISPLAY UNIT
3.8 CONNECTING TO THE GYRO AND ELECTROMAGNETIC LOG (NSK UNIT SETTING)
3-25
3
NSTALLATION MANUAL
S5 SETTING TABLE
12345678
STEP
ON
SYNC
OFF
ON ON
OFF ON
ON OFF
OFF OFF
ON
OFF
ON
OFF
N.C.
any
ON ON
OFF ON
ON OFF
OFF OFF
200P/90×
400P/180×
800P/360×
NOR
RATIO
36×
90×
180×
360×
DIRECTION
REV
GYRO SIGLOG SIG
TYPE
TYPE
SYNC
PULSE
Don't care
PULSE
100P/30×
Speed log switch setting
1 This radar's compatible standard speed logs are the following eight types:
Pulse type: 800 pulses/NM, 400 pulses/NM, 200 pulses/NM, 100 pulses/NM
Synchro type: 360X/NM, 180X/NM, 90X/NM, 30X/NM
Set the S5 GYRO/LOG select switch according to the S5 setting table.
2 Connect the speed log signal input line to TB20.
To do so, for the pulse type, connect the line to the PULSE side and, for the synchro
type, connect the line to the SYNC side. With respect to the positive (+) and
negative (-) sides, when the pulse type is selected, the negative (-) side is the ground.
Setting of JMA-3300
Heading Equipment Setting
For details of operations, refer to "4.1 OPENING THE ADJUST MENU" "4.7.2
HEADING EQUIPMENT".
1 Hold down the [MENU] key.
"Code Input" screen appears.
2 Input "0" using the cursor keys, then press the [ENT] key.
"Adjust Menu" screen appears.
3 Press the cursor keys to select I/F Device , then press the [ENT] key.
"I/F Device" screen appears.
4 Press the cursor keys to select Heading Equipment , then press the [ENT]
key.
Selectable items for "Heading Equipment" are displayed.
5 2. Set the gyro.
To Next Page
