Parts list
◯ Removing parts list
◯ Installing parts list
• Automatic presser foot lifter components (for all models)
• Pneumatic device components (in case of LU-1510-7)
• Pneumatic device components (in case of LU-1510, LU-1508 and LU-1508H)
• Kit A (knee lifter switch)
Note No. Part No. Name of part Q’ty Remarks
1 GAKA14020A0 Cord (asm.) 1
2 GAKA14030A0 Solenoid valve (asm.) 1
3 GAK29010000 Quick joint (elbow) 1
4 GAK29015000 Quick joint (straight) 1
5 GAK29016000 Speed controller 1
6 BT0600401EB Air hose 2 1.3 m
7 BT0600401EB Air hose 1 0.18 m
8 HX00123000A Cord presser 1
9 PJ309065202 Quick joint (branch elbow Y) 1
10 SM4034001SN Solenoid valve setscrew 2
11 HX002950000 Wire mark 3 1
12 HX00295000A Wire mark 3 2
Note No. Part No. Name of part Q’ty
GAKA19010A0 Automatic presser foot lifter (asm.) 1
1 PA400150100 Automatic presser foot lifter cylinder 1
2 SM6082502TP Cylinder installing screw 4
3 21356506 Cylinder connecting screw 1
4 NM6080001SE Nut 1
5 SD0720331SP Hinge screw 1
6 21356605 Automatic presser foot lifter lever A 1
7 21656803 Automatic presser foot lifter lever B 1
8 SM6051002TP Automatic presser foot lifter lever B setscrew 2
9 21356704 Automatic presser foot lifter lever shaft 1
10 PJ304065102 Elbow 2
11 21356308 Automatic presser foot lifter cylinder stay (front) 1
12 21356407 Automatic presser foot lifter cylinder stay (rear) 1
13 SS6151040SP Cylinder stay attaching screw 4
14 CM3002000B1 Caution seal for being caught 1
15 CM300200001 Caution seal for injury to finger 1
Note No. Part No. Name of part Q’ty
1 21332309 Side plate cover 1
2 SS4110815SP Side plate cover setscrew 1
Note No. Part No. Name of part Q’ty
1 GAKA14010A0 Pneumatic components (asm.) 1
Note No. Part No. Name of part Q’TY
1 GAKA14040D0 Presser foot lifter knee switch B (asm.) 1
2 SK3514000SC Knee switch (asm.) installing wood screw 2
