JUKI LU-1508H Engineer's Manual

−50 −
● For LU-1510
● For LU-1510-7
● For LU-1508
Hook shaft upper bushing thrust washer is the same as that for LU-1510. (See the above table.)
● For LU-1508H
Hook shaft upper bushing thrust washer is the same as that for LU-1510. (See the above table.)
6. SELECTIVE PARTS AND CONSUMABLE PARTS
Consumable part Part No. Remarks
Needle MC372001600 SCHMETZ 135x17 Nm 160
Hook (asm.) B18305630A0
Bobbin B9117563000
Name of selective part Part No. Marking Remarks
Hook shaft upper bushing thrust washer 10109700 0 t=1.0 mm
Ditto 10110906 1 t=1.1 mm
Ditto 10111003 2 t=1.2 mm
Ditto 10111102 3 t=1.3 mm (standard)
Ditto 10111201 4 t=1.4 mm
Ditto 10109809 5 t=1.5 mm
Ditto 10112506 6 t=1.6 mm
Ditto 10102605 7 t=1..7 mm
Ditto 10102704 8 t=1.8 mm
Consumable part Part No. Remarks
Needle MC372001600 SCHMETZ 135x17 Nm 160
Hook (asm.) 21334552
Bobbin 21334800 Aluminum bobbin (with knurl)
Counter knife base (asm.) 21354857 (With moving knife, counter knife and clamp spring)
Moving knife 10726305
Counter knife 10726404
Clamp spring 10726909
Consumable part Part No. Remarks
Needle MC372001600 SCHMETZ 135x17 Nm 160
Hook (asm.) B18305630A0
Bobbin B9117563000
Consumable part Part No. Remarks
Needle MC0190R1600 SCHMETZ 190 Nm 160
Hook (asm.) B1830563BA0 For extra thick thread
Bobbin B9117563000
Name of selective part Part No. Marking Remarks
Hook shaft upper bushing thrust washer 22614002 A t=1.9 mm
Ditto 22614101 B t=2.0 mm (standard)
Ditto 22614200 C t=2.1 mm
Ditto 22614309 D t=2.2 mm
Ditto 22614408 E t=2.3 mm
Ditto 22614507 F t=2.4 mm
