– 39 –
4-11. Custom switch
Operations can be assigned to machine head switches
①
to
⑥
, hand switch
⑦
and jog dial
⑧
.
The initial values (states) are as described below.
①
Machine head switch 1: One touch changeover switch 1
②
Machine head switch 2: One touch changeover switch 2
③
Machine head switch 3: One touch changeover switch 3
④
Machine head switch 4: Cancellation/addition switch for automatic reverse feed stitching
⑤
Machine head switch 5: Needle entry alignment switch
⑥
Machine head switch 6: Thread clamp switch
⑦
Hand switch: Reverse feed stitching switch
⑧
Jog dial: Needle up/down correction switch
1)
❶
held pressed for three second.
The "mode screen" is displayed.
2) Select the "13. Hand switch setting".
①
② ③ ④ ⑤ ⑥
⑦
⑧
❶
To Next Page
