Threading 4/3 Thread OL
2. Lower looper thread, red markings
Place the spool on the spool holder pin as illustrated.
(1) Bring the thread up from spool and lay it from the back to
the front into the guide.
(2) Thread the first machine guide.
(3) Slip the thread through the groove.
(4,5,6,7) Thread the guides (4&5), follow the slit guide (6),
then thread (7).
(8) Press the lever of the auto threader down.
(9,10) Thread the guide and then the slit on the threader.
Push the auto threader lever up to return to its normal
position.
(11) Thread the lower looper eye and place the thread under-
neath the presser foot.
Note:
If the lower looper has to be re-threaded, cut both needle
threads off at the needle and remove surplus thread from be-
low. Thread the lower looper and then re-thread the needles.
23
