Cover/chain stitch functions and general operating instructions
Knife guard / cover and chain stitch extension plate
When the machine is converted to cover/chain stitch, the knife guard
in the looper cover is replaced by cover stitch extension plate. The
extension plate covers the released upper looper and extends the
stitch plate to the right of the presser foot.
To replace:
1) Open the looper cover.
2) Remove the knife guard by pulling gently to the left.
3) To attach the extension plate, hold it at a slight angle to the loop-
er cover.
4) Position, hold both parts parallel.
5) Push the plate to the right until it clicks into place.
CAUTION :
For safety, the power is automatically cut o when you open
the looper cover or the cloth plate.
33
