Initial operation
38
7.2.2 Connect refrigerated circulator
This section describes how the circulator is connected as a refrigerated
circulator.
The circulator is mounted on a refrigeration unit.
The connection cable, mains cable and CAN bus cable are ready for use.
1. Connect the connection cable [1] of the circulator with the refrigeration
unit.
2. Connect the CAN plugs of both units with the CAN bus cable [2].
3. Connect the refrigeration unit to mains power [3] using the power cable.
The refrigerated circulator is connected. Alternatively, the units can be
connected to separate circuits. If necessary, the power supply must be set
up in the unit setting.
