Julabo FP52-SL - Page 12

Operator responsibility – Safety recommendations
12
Ultra-Low Refrigerated Circulator
FPW91-SL
water-cooled
Working temperature range °C -91 ... 100
Temperature stability °C ±0.2
Cooling capacity
Medium ethanol
°C
kW
+20 0 -20 -40 -60 -80
4.5 4.1 3.7 3.1 2.0 0.75
Cooling compressor 2-stage
Refrigerant R404A / R23
Cooling water flow rate at 20 °C l/h approx. 450
Overall dimensions (WxDxH) cm 85x76x116
Filling port dia. cm 7
Special unit with bath opening
(WxL)
cm 28x23
Bath depth cm 20
Filling volume liters 22
Weight kg 216
Ambient temperature °C 5 ... 40
Cooling water connection G3/4“ male thread
Mains power connection V/ Hz 400 V/3PNPE/ 50 Hz
Current draw (at 400 V) A 32
Mains power connection V/ Hz 230 V/3PPE/ 60 Hz
Current draw (at 230 V) A 32
 Current draw: Refer to notice page 15
All measurements have been carried out at: rated voltage and frequency ambient temperature: 20 °C
Technical changes without prior notification reserved.
