Anhang: HST Zusatzheizer und HSP Zusatzpumpe
Upgradable with supplementary heater - HST
 For control a HST booster heater a electronic module is
required.
Order No. Description
8810012 HST booster heater 6 kW
8900100 Electronic module
Technical specifications on page 99
Upgradable with supplementary pump – HSP
Order No. Description
8810015 HSP booster pump, 30 l/min. –3 bar max.
Technical specifications on page 101
Caution:
To ensure full operating safety, the HST booster heater and HSP booster pump must be
securely fixed to the refrigerated bath using the screws supplied with the unit!
Top view:
HST
HSP
19a
19b
SL
circulator
Mounting the optional devices:
On the basic version of the ultra-low refrigerated circulator, the
mounting openings for the HSP booster pump and the HST booster
heater are closed with stainless steel lids.
• If the optional devices are retrofitted, remove the four screws on
each of the stainless steel lids.
• Place the booster pump and/or the booster heater in the
respective opening and fix it using the screws supplied with the
unit.
Connecting the power cable and the control cable:
• For the circulator basic version see page 21 and page 31
• For the HST booster heater see page 98
• For the HSP booster pump see page 100
