JUMO diraTRON 104 User Manual

7 Configuration
68
Response in case of a fault
In the event of a fault (above or below the measuring range, probe/conductor breaks or probe/conductor
short-circuits), the ramp function is interrupted. Once the fault is over, the actual value is applied as the
current ramp value.
Behavior after power on
After power on, the actual value is applied as the current ramp value (ramp starts).
7.10 Program controller
Off signal Digital selector
No selection
Signal (high active) for switching off the ramp func-
tion (setpoint value immediately assumes the
specified end value)
Restart signal Digital selector
No selection
Signal (high-active) for aborting and restarting the
ramp (with actual value as setpoint value)
Additional functions
(setup only)
Parameter 1
parameter 2
Reserved functions for service purposes. Only ac-
tivate when instructed to do so by service person-
nel!
Click checkbox to activate the function.
Parameter Selection/text/value Description
Parameter Selection/text/value Description
Function Fixed-setpoint con-
troller
The device operates as a fixed-setpoint controller
("Fixed value" operating mode).
Program controller The device operates as a program controller ("Au-
tomatic" and "Stop" operating modes).
Time display Time unit for displaying the program times
mm:ss Minutes:Hours
hh:mm Hours:Minutes
dd:hh Days:Hours
Program start Program start The program starts at the first programmed set-
point value.
Actual value The programs starts with the actual value as the
first setpoint value.
Start with power on
(setup only)
No No automatic program start after power on
Yes Automatic program start after power on
Lead time
(setup only)
0 to 9999 Delay time (in seconds) for program start
Tolerance band 0 to 9999 Tolerance band around setpoint value (for monitor-
ing the setpoint value)
0 = tolerance band not active
Program repeat
(setup only)
No No program repeat
Yes The program is cyclically repeated.
Program progression
step
No Setpoint value change as ramp
Yes Setpoint value change as step
Actual value input Analog selector
Analog input
Analog signal as actual value of the controller
?
?
