9 Online parameter (setup only)
90
9.4 Additional process values for online data
Additional process values to be displayed in the online data window of the setup program are selected
in this window ("Additional process values" tab).
After pressing the "Edit" button (or double clicking on the relevant line), the process value for the previ-
ously marked line can be selected:
Parameter Selection/text/value Description
Process value Select the process value
from the selector (drop-
down menu)
No selection
Analog signal, digital signal, or value of a configu-
ration parameter
The selection you make is displayed in the online
data "Selector" column along with the complete
path from the selector. The value of the process
value is shown in the "Value" column.
Additional identifier Enter text (max. 30 char-
acters)
Individual designation of the process value
The text is shown in the online data "Identifier" col-
umn.
Unit Enter text (max. 6 char-
acters)
Process value unit
The text is shown in the online data "Unit" column.
