2 Installation - Electrical Connection
8
Electrical data
Site altitude up to 2000 m above sea level
Operating position any
Protection type as per DIN EN 60529, at the front IP 65, at the rear IP 20
Weight (fully equipped) LC100: approx. 150 g; LC200: approx. 200 g;
LC300: approx. 300 g
Voltage supply (switch
mode PSU)
AC 110 to 240 V +10/-15 %, 48 to 63 Hz
AC/DC 20 to 30 V, 48 to 63 Hz
Electrical
safety
as per DIN EN 61010, part 1
overvoltage category III, pollution degree 2
Power consumption max. 14 VA
Electrical connection on the rear via screw terminals; with core-end ferrule of a pipe
shape, open cable lug or pin cable lug
Conductor cross section fine-strand 0.25 to 1.5 mm
2
Tightening torque 0.5 Nm
Electromagnetic
compatibility
as per DIN EN 61326-1
Interference emission Class A - Only for industrial use -
Interference immunity Industrial requirements
Setup interface USB socket, type Mini-B 5-pole
