Jungheinrich ERC-Z12 User Manual

0602.GB
E 4
*
)
only at ERC-Z 14/16
Pos. Controls or
indicating instrument
respectively
ERC
12
ERC
14/16
ERC-Z
12/14/16
Function
10 Button -
Lifting the lifting device
tt t Lifting the lifting device.
The lifting speed can be conti-
nuously adjusted with this key
(adjustment range 8 mm).
11 Button -
Lowering the lifting de-
vice
tt t Lowering the lifting device.
The lowering speed can be
continuously adjusted with
this key (adjustment range 8
mm).
12 Terminal strip tt t Depositing of freight docu-
ments.
13 Master switch
(Emergency Stop)
tt t The circuit is interrupted, all
electric functions are switched
off. The truck is compulsory
braked.
14 Control lamp at the
battery charger
oo Indicates the loading states
(see chapter D).
15 Integrated battery char-
ger
oo Used for recharging the batte-
ry.
16 Hinged driver standing
platform
tt t Pedestrian-controlled operati-
on:
Driver standing platform in fol-
ded- up position:
=>Truck travelling speed is li-
mited to 6.0 km/h.
Stand-on operating mode:
standing platform serves as
deadman's switch function:
Unweighted standing platform
in folded-down position:
=>travelling function blocked.
Standing platform in folded-
down position, driver stan-
ding on platform:
=>travelling function rleased.
17 Hinged safety extensi-
ons
-
tt*
)
The travelling function is blok-
ked if the safety extensions
are not folded out when the
standing platform is folded
down.
t = Standard equipment o = Optional equipment
0602.GB
E 4
*
)
only at ERC-Z 14/16
Pos. Controls or
indicating instrument
respectively
ERC
12
ERC
14/16
ERC-Z
12/14/16
Function
10 Button -
Lifting the lifting device
tt t Lifting the lifting device.
The lifting speed can be conti-
nuously adjusted with this key
(adjustment range 8 mm).
11 Button -
Lowering the lifting de-
vice
tt t Lowering the lifting device.
The lowering speed can be
continuously adjusted with
this key (adjustment range 8
mm).
12 Terminal strip tt t Depositing of freight docu-
ments.
13 Master switch
(Emergency Stop)
tt t The circuit is interrupted, all
electric functions are switched
off. The truck is compulsory
braked.
14 Control lamp at the
battery charger
oo Indicates the loading states
(see chapter D).
15 Integrated battery char-
ger
oo Used for recharging the batte-
ry.
16 Hinged driver standing
platform
tt t Pedestrian-controlled operati-
on:
Driver standing platform in fol-
ded- up position:
=>Truck travelling speed is li-
mited to 6.0 km/h.
Stand-on operating mode:
standing platform serves as
deadman's switch function:
Unweighted standing platform
in folded-down position:
=>travelling function blocked.
Standing platform in folded-
down position, driver stan-
ding on platform:
=>travelling function rleased.
17 Hinged safety extensi-
ons
-
tt*
)
The travelling function is blok-
ked if the safety extensions
are not folded out when the
standing platform is folded
down.
t = Standard equipment o = Optional equipment

Jungheinrich ERC-Z12 Specifications

General

Brand	Jungheinrich
Model	ERC-Z12
Category	Forklifts
Language	English
