Jungheinrich ERC-Z12 User Manual

E 7
0602.GB
Switching on the truck
– Pull up the master switch (13).
– Insert the key in the key switch (3) and turn the key clockwise towards the “I”
position until reaching the stop.
– When a code lock is installed, you must enter an operator code
(refer to section 6.6).
– Check the horn (5) for correct functioning.
A
The combination instrument (CANDIS (o) (2)) shows the available battery capacity.
f
When swivelling the driver’s standing platform (16) upwards, do not reach between
the driver’s standing platform and the truck’s side wall.
– To initialise the truck, actuate the controller (8) once while the driver’s standing plat-
form (16) is folded up.
– Check the service and counter-current brake for correct functioning
(refer to section 4.2).
The truck is now ready for operation.
5
1
16
13
2
3
8
E 7
0602.GB
Switching on the truck
– Pull up the master switch (13).
– Insert the key in the key switch (3) and turn the key clockwise towards the “I”
position until reaching the stop.
– When a code lock is installed, you must enter an operator code
(refer to section 6.6).
– Check the horn (5) for correct functioning.
A
The combination instrument (CANDIS (o) (2)) shows the available battery capacity.
f
When swivelling the driver’s standing platform (16) upwards, do not reach between
the driver’s standing platform and the truck’s side wall.
– To initialise the truck, actuate the controller (8) once while the driver’s standing plat-
form (16) is folded up.
– Check the service and counter-current brake for correct functioning
(refer to section 4.2).
The truck is now ready for operation.
5
1
16
13
2
3
8
