15
03.13 EN
B Truck Description
1 Application
The DFG / TFG 425s - 435s is a four-wheel sit-down industrial truck with a combustion
engine. The DFG series are diesel engine trucks, while the TFG series are fitted with
a petrol engine for LPG operation.
The DFG / TFG 425s - 435s is a cantilever counterbalanced truck which can lift,
transport and deposit loads using the load handler attached in front.
The DFG / TFG 425s - 435s is equipped with a hydrostatic drive. The combustion
engine drives high pressure pumps for the hydraulic functions and two hydraulic
motors to drive the wheels.
1.1 Truck models and rated capacity
The rated capacity depends on the model. The rated capacity can be derived from the
model name.
The rated capacity is not generally the same as the permissible capacity. The capacity
can be found on the capacity plate attached to the truck.
DFG435s
DFG Model name
4Series
35 Rated capacity x 100 kg
s Hydrostatic Drive System
