Jungheinrich TFG 425s User Manual

03.13 EN
22
3.2 Dimensions
*) The data listed in the table corresponds to the standard version.
DFG/TFG 425s-435s
Component DFG/TFG
425s
DFG/TFG
430s
DFG/TFG
435s
a/2 Safety distance 100 100 100 mm
h
1
Collapsed height* 2315 2333 2433 mm
h
2
Free lift* 150 150 150 mm
h
3
Lift* 3300 3300 3300 mm
h
4
Extended height* 3910 4070 4083 mm
h
6
Overhead guard height* 2220 2238 2238 mm
h
7
Seat height* 1058 1076 1076 mm
h
10
Coupling height 380 400 400 mm
Į Mast tilt, fwd.* 6 6 6 °
ȕ Mast tilt, back* 8 8 8 °
l
1
Overall length, including
forks*
3763 3858 3948 mm
l
2
Overall length, including
fork shank*
2613 2708 2798 mm
b1 Overall width* 1184 1320 1320 mm
s/e/l Fork dimensions* 40/120/1150 45/125/1150 50/125/1150 mm
m
1
Ground clearance,
laden, below mast*
125 143 143 mm
m
2
Ground clearance
centre wheelbase*
130 148 148 mm
Fork carriage ISO 2328,
class / type A, B
2A 3A 3A
A
st
Aisle width for pallets
800 x 1200 lengthways
4158 4260 4338 mm
A
st
Working aisle width for
pallets 1000 x 1200
traverse
3958 4060 4138 mm
W
a
Turning radius 2285 2377 2455 mm
b
13
Smallest turning radius 617 641 657 mm
x Load distance* 473 478 483 mm
c Load centre of gravity 500 500 500 mm
y Wheelbase 1750 1820 1880 mm
