17
03.13 EN
2.2 Assembly Overview
Item Component Item Component
5 t Driver's seat 13 t Drive system
6 t Overhead guard 14 t Emergency Disconnect switch
7 t Steering wheel 15 t Engine bonnet
8 t Mast 16 t Steer axle
9 t Fork carriage 17 t Counterweight
10 t Fork tines 18 t Trailer coupling
11 t Lifting mechanism control 19 t LPG bottle (TFG only)
12 t Operating and control unit
t = Standard equipment o= Optional equipment
5
11
12
14
10
13
16
18
17
15
19
