Juniper ACX5448 User Manual

Figure 21: Install the ACX5448-M Router in a Four-Post Rack
g100709
7. Install mounting screws into each of the open front-mounting bracket holes aligned with the rack, starting from the
bottom, and secure them tightly. Figure 22, Figure 23, and Figure 24show the router fully secured to the front rails of
the four-post rack.
Figure 22: ACX5448 Router Secured by Front-Mounting Brackets
g100131
Figure 23: ACX5448-D Router Secured by Front-Mounting Brackets
g100534
13
