Juniper CTP Series Hardware Guide

Table 7: V.24 Connector Interface Signals for HD-26 to RJ-45 (continued)
DescriptionRJ-45 PinHD-26 Pin
CD26
CTS78
RTS811
GND424, 26
T1/E1 Interface Signal Pinouts (RJ-45 Male)
Table 8 on page 33 lists the T1/E1 interface module pinout for the RJ-45 connector.
Table 8: T1/E1 Interface Module—RJ-45 Connector Pinout
SignalRJ-45 Pin
RX Ring1
RX Tip2
–3
TX Ring4
TX Tip5
–6
–7
–8
RELATED DOCUMENTATION
CTP150 Console Cable Pinouts | 34
CTP Fast Ethernet and Power Cables | 36
33
