Juniper CTP2000 Series User Manual

NOTE: Tighten the captive screws completely before installing an adjacent
module so that proper electromagnetic interference (EMI) gasket
compression occurs. Failure to do this can make it difficult to install
adjacent modules.
Install a CompactFlash Card
On the CTP2000 series devices with the new PP833 processor, the CompactFlash card
is installed on the processor itself (which may be located under an installed PMC card),
which prevents insertion or removal of the CompactFlash card until the PMC card is
removed. On the CTP2000 series devices with the PP310 and PP332 processors, the
CompactFlash card is installed on the processor rear transition module (RTM). Some
CTP devices may ship with a CompactFlash card already installed.
To remove or install the CompactFlash card for the CTP2000 series devices with the
new PP833 processor (see Figure 1 on page 9):
1. Power off the unit.
2. If installed, remove the PP833 PMC card by unscrewing the retaining screws and
pushing the extractors outward with the latching buttons depressed.
3. You can then remove or install the CompactFlash card in the flash socket.
4. If being used, reinstall the PP833 PMC card into the chassis, and secure the retaining
screws.
Figure 1: Installing CompactFlash on the PP833 processor
9Copyright © 2019, Juniper Networks, Inc.
Step 3: Install Modules and Other Components
