Juniper CTP2024 Hardware Guide

CHAPTER 6
Cable and Pinout Specifications
IN THIS CHAPTER
CTP2000 4WE&M Interface Connector Pinouts | 45
CTP2000 FXS and FXO Interface Module Cables and Pinouts | 48
T1/E1 Interface Module Pinouts | 51
CTP2000 Serial Interface Module Pinouts | 52
CTP2000 Series Console Cable Pinouts | 63
CTP Fast Ethernet and Power Cables | 68
Terminal Block and Circuit Breaker Specifications | 69
CTP2000 4WE&M Interface Connector Pinouts
IN THIS SECTION
CTP2000 4WE&M RTM Connector A Pinouts | 45
CTP2000 4WE&M Connector B Pinouts | 46
CTP2000 4WE&M RTM Connector A Pinouts
See Table 11 on page 45 for connector A pinout information. See “CTP2000 4WE&M Interface Module”
on page 14 for signal definitions.
Table 11: CTP2000 4WE&M RTM Pinouts–Connector A
Connector A
PinSignalSignalPin
26Port 0 TPort 0 R1
45
