Table 14: CTP2000 FXO Connector Pinouts on the RTM
PinSignalSignalPin
26Port 0 RPort 0 T1
28Port 1 RPort 1 T3
30Port 2 RPort 2 T5
32Port 3 RPort 3 T7
34Port 4 RPort 4 T9
36Port 5 RPort 5 T11
38Port 6 RPort 6 T13
40Port 7 RPort 7 T15
42Port 8 RPort 8 T17
44Port 9 RPort 9 T19
46Port 10 RPort 10 T21
48Port 11 RPort 11 T23
RELATED DOCUMENTATION
CTP2000 2W-FXS and 2W-FXO Interface Modules | 20
CTP2000 4WE&M Interface Connector Pinouts | 45
CTP2000 Series Console Cable Pinouts | 63
CTP Fast Ethernet and Power Cables | 68
T1/E1 Interface Module Pinouts
Table 15 on page 52 lists the T1/E1 interface module pinouts for the RJ-45 connector.
