Table 15: T1/E1 Interface Module—RJ-45 Connector Pinout
SignalRJ-45 Pin
RX Ring1
RX Tip2
–3
TX Ring4
TX Tip5
–6
–7
–8
RELATED DOCUMENTATION
CTP2000 T1/E1 Interface Module | 13
CTP2000 FXS and FXO Interface Module Cables and Pinouts | 48
CTP2000 Series Console Cable Pinouts | 63
Cabling a CTP2000 T1/E1 Interface Module | 111
CTP2000 Serial Interface Module Pinouts
Figure 30 on page 53 displays the serial DCE/DTE cable pin configurations for CTP2000 series devices.
