Table 19: CTP2000 Series Console Cable (p/n 720-071594) Pinouts for the PP833 Processor (continued)

DB-9 MaleUSB Console Connector

5 GND4 GND

Table 20: DB9-to-RJ45 Adapter (p/n 450-071855) Pinouts for Connecting PP833 Processor with Console

DB-9RJ-45

5 GND3 TXD

3 TXD4 GND

2 RXD5 GND

Table 21: DB9-to-RJ45 Adapter (p/n 720-056657) Pinouts to Convert PP833 Console to CTP150 Console

Pinout

DB-9RJ-45

7 RTS1 RTS

4 DTR2 DTR

3 TXD3 TXD

5 GND4 GND

2 RXD6 RXD

6 DSR7 DSR

8 CTS8 CTS

Table 22: DB9-to-RJ45 Adapter (p/n 720-014126) Pinouts for Connecting PP833 Processor with a PC

DB-9RJ-45

8 CTS1 RTS

6 DSR2 DTR

2 RXD3 TXD

5 GND4 GND
