Juniper CTP2024 Hardware Guide

Figure 32: Upgrading from PP310/PP332 Processor to PP833 Processor
5—1— Cable 720-071594PP332 front panel
6—2— DB-9 male end of 720-071594PP332 RTM panel
7—3— Adapter 450-071855User’s existing console cable
8—4— RJ-45 male end of user’s existing console cablePP833 front panel
Figure 33: Connecting the PP833 Processor with the RJ-45 Serial Console
4—1— Adapter from the bag labelled 720-056657PP833 front panel
5—2— RJ-45 male end of user’s console cableCable 720-071594
6—3— User’s cable that connects to the console on a
CTP150 or other Juniper product
DB-9 male end of 720-071594
67
