Figure 131: Connect a SFP28, SFP+, or QSFP-DD Direct Aach Cable
1— Transceiver 2— Port on the device
6. Repeat Step 5 for all ports to which the cable must be connected.
7. Secure the cable so that it does not support its own weight as it hangs to the oor. If there is a cable
management system, arrange the cable in the cable management system to prevent the cable from
dislodging or developing stress points. Place excess cable out of the way in a neatly coiled loop in the
cable management system. Placing fasteners on the loop helps to maintain its shape.
The procedure to connect other types of direct aach cables, other than direct aach breakout cables, is
the same as the procedure described in this topic.
Maintain Acve Opcal Cables
IN THIS SECTION
Disconnect an Acve Opcal Cable | 231
Connect an Acve Opcal Cable | 233
An acve opcal cable (AOC) is an opcal ber cable that has a transceiver preaached to each end.
