To install a fan tray controller:
1. Remove the replacement fan tray controller from the electrostatic bag.
2. Carefully slide the fan tray controller into the fan tray controller slot until it is flush with the mounting
holes. See Figure 86 on page 190.
Figure 86: Replacing an MX10008 Fan Tray Controller
3. Using a Phillips screwdriver, tighten the captive screws for the fan tray controller.
4. Replace the fan tray. See “Installing an MX10008 Fan Tray” on page 183.
SEE ALSO
Installing an MX10008 Fan Tray | 183
Removing an MX10008 Fan Tray Controller | 186
Removing an MX10008 Fan Tray | 179
