Table 58: Setting the JNP10K-PWR-DC2 Dip Switches (continued)
FieldStateSwitch
Enabled for 30 A feed; 5500-W for a single feed, 5000-W for dual feedsOn3
Enabled for 20 A feed; power supply capacity is 3000-WOff
Figure 141: Setting the Enable Routers for the Power Source
2—1— Power switch, on (|) and standby (O)Dip switches
19. Verify that the input 1 and 2 LEDs on the power supply faceplate are lit and are on steadily.
20. Press the power switch to the on (|) position.
243
