3. Take care not to strike the unit against any object as you carry it.
CAUTION: Never hold the line card or RCB by the connector edge. The connectors
are fragile and the line card or RCB will not seat properly if the connector is damaged.
See Figure 142 on page 245.
Figure 142: Connector Edge of a Line Card
1—Connectors
4. If you must rest a line card or RCB on an edge, place a cushion between the edge and the surface.
CAUTION: Do not stack line cards or RCBs on top of one another or on top of any
other component.
5. Place each line card or RCB in an individual electrostatic bag or separately on an antistatic mat that is
placed on a flat, stable surface.
245
