SEE ALSO
1.2 Terabyte DWDM OTN Module Wavelengths | 116
1.2 Terabyte DWDM OTN Module Wavelengths
The PTX10K-1104 coherent line card and the QFX10000-12C-DWDM line card provides six 200-Gbps
coherent MACsec ports with built-in long-reach optics. DWDM channel frequency offsets are 0.02 THz.
The QFX10000-12C-DWDM line card is available for QFX10008 and QFX10016 switch chassis running
Junos Os Release 17.3R1 and later. The PTX10K-1104 coherent line card is available for PTX10008 and
PTX10016 line cards. See Table 40 on page 116 for the available channel frequencies and wavelengths.
Table 40: DWDM Module Wavelengths
OffsetWavelength (nm)Frequency (THz)
12.5/50 GHz1566.72191.35
12.5 GHz1566.62191.36
12.5 GHz1566.52191.38
12.5 GHz1566.42191.39
12.5/50/100 GHz1566.31191.4
12.5 GHz1566.21191.41
12.5 GHz1566.11191.43
12.5 GHz1566.01191.44
12.5/50 GHz1565.91191.45
12.5 GHz1565.8191.46
12.5 GHz1565.7191.48
12.5 GHz1565.6191.49
12.5/50/100 GHz1565.5191.5
12.5 GHz1565.39191.51
