Table 72: RJ-45 Management Port Connector Pinouts for the PTX10000 Series (continued)
DescriptionSignalPin
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4–8
SEE ALSO
PTX10000 Routing and Control Board LEDs | 81
