SEE ALSO
Handling and Storing PTX10000 Line Cards, Routing and Control Boards, and SIBs | 321
Installing a PTX10000 Routing and Control Board | 247
PTX10000 Routing and Control Board LEDs
IN THIS SECTION
Routing and Control Board Status Panel LEDs | 82
PTX10000 Management Port LEDs | 83
SATA SSD LEDs | 84
Clock LEDs (JNP10K-RE1, JNP10K-RE1-LT, and JNP10K-RE1-128) | 85
The PTX10000 Routing and Control Boards (RCBs) have four types of LED indicators (see
Figure 41 on page 81).
Figure 41: PTX10000 Routing and Control Board (JNP10K-RE0) LEDs
g050577
1 2 3 4
3—1— SATA SSDRouting and Control Board status panel
4—2— Virtual port connectionManagement ports
Figure 42: PTX10000 Routing and Control Board (JNP10K-RE1) LEDs
g100067
2 31
3—1— Clock LEDs—BITS-0 and BITS-1Routing and Control Board status panel
2—SSD LEDs—DISK1 and DISK2
81
