Clock LEDs (JNP10K-RE1, JNP10K-RE1-LT, and JNP10K-RE1-128)
The clock LEDs indicate the status of the clock.
Table 24 on page 85 describes the clock LEDs.
Table 24: Routing and Control Board Clock Status LED
DescriptionStateColorLED
Clock is active.OffRedClock LEDs—BITS-0 and
BITS-1
Clock is not working.On steadily
RELATED DOCUMENTATION
Connecting a PTX10000 to a Network for Out-of-Band Management | 237
Handling and Storing PTX10000 Line Cards, Routing and Control Boards, and SIBs | 321
Installing a PTX10000 Routing and Control Board | 247
PTX10008 Switch Fabric
IN THIS SECTION
PTX10008 Switch Interface Board Description | 86
PTX10000 Switch Interface Board LEDs | 88
The PTX10000 Switch Interface Boards (SIBs) form the switch fabric for the router.
