Figure 47: SIBs Installed in a PTX10008
g050555
2
1
1
2—1— SIBsFan tray controllers
SEE ALSO
Installing a PTX10000 Switch Interface Board | 326
Removing a PTX10000 Switch Interface Board | 332
PTX10000 Switch Interface Board LEDs
The Switch Interface Board (SIB) has two status LEDs at the top of each board. See Figure 48 on page 89.
