Figure 46: Enhanced SIB for 14.4 Terabyte Line Cards
Table 25 on page 87 shows the physical specifications for a PTX10008 SIB.
Table 25: Dimensions of a PTX10008 SIB
ValueSpecification
19.7 in. (50.04 cm)Height
1.8 in. (4.57 cm)Width
10.4 in. (26.42 cm)Depth
14.8 lb (6.71 kg)Weight
SIBs are hot-removable and hot-insertable field-replaceable units (FRUs). They are not visible from the
outside of the router chassis. You must remove one of the fan trays in order to view the SIBs. The SIBs
are numbered from left to right SIB0 to SIB5. See Figure 47 on page 88.
87
