Table 21: SFP Management Port LEDs on a PTX10000 Routing and Control Board (JNP10K-RE0 and
JNP10K-RE1)
DescriptionStateColorLED
No transceiver is present.OffUnlitLink/Activity/Status
A link is established. The interface is up.On steadilyGreen
The beacon feature is enabled.Blinking or flickeringGreen
An error has occurred.BlinkingYellow
Table 22: JCS Port LEDs on a MX10008 Routing and Control Board (JNP10K-RE1)
DescriptionStateColorLED
No transceiver is present.OffUnlitLINK LEDs for
JCS ports
(XGE0 and
XGE1)
A link is established. The interface is up.On steadilyGreen
The beacon feature is enabled.Blinking or flickeringGreen
An error has occurred.BlinkingYellow
SATA SSD LEDs
The Serial Advanced Technology Attachment (SATA) solid-state drive (SSD) LEDs indicate the status of
the secondary drive.
Table 23 on page 84 describes the LEDs for the secondary SATA drive.
Table 23: Routing and Control Board SSD Status LEDs
DescriptionStateColorLED
A SATA drive is present.On steadilyGreenSSD on JNP10K-RE0
DISK1 and DISK2 on
JNP10K-RE1
The drive is active.BlinkingGreen
The drive is active.On steadilyYellow
A drive is not installed.UnlitDark
84
