Figure 1: PTX10008 Chassis Front
g050552
1
2
3
4
4
5
4
4
4—1— Installation holes for the front panelRouting and Control Boards
5—2— Line card slots 0-7 (numbered top to bottom)Status LED panel
3—Handles
Some chassis ship with an enhanced power bus to support the power needs of higher wattage line cards.
Chassis with the enhanced power bus have a modified Status Panel (see “PTX10000 Status Panel LEDs”
on page 41).
