Figure 2: PTX10008 Chassis Rear
FAN
FTC
SIB STATUS
FAN
FTC
SIB STATUS
2—1— Fan trays with redundant fansAC or DC power supplies
Figure 3 on page 28 illustrates the components that are internal to the chassis.
27
